We provide
meters of high accuracy in measurement, which give you
a better solution for analysis, in energy management
and power measurement.
The NEMO series of multifunction meters
New launched NEMO 96 HD
with Plug-in options
| Features
A network analyzer with plug in options
96 x 96 ,flush mounting
measures ;
u- all voltages –phase &link,mini/max
per phase, thd
I – phase &neutral ,phase demand Max.Ademand,
A sum, thd
PQS-Power –three pahse,/per phase/demand/max.demand
Active, reactive, apparent
ET – power factor, frequency, run hour,
Total positive & negative active energy
Total positive & negative reactive energy
Display : 4-line with bar graph
Aux supply : 90- 265vac, 110-300vdc in same model
Current input : 5A and 1A same model
Plug in options for communications RS485
Communication RS232
Pulse output , analog outputs
Alarms |
 |
| NEMO 72L |
| L.v.
application network monitor for 3-phase and single
phase
Measures : A,Aneutral, Amd, Amax md, THD
V,PF,HZ, P,Q,S,per phase /demand /max-demand
Kwh, kvarh, run hour, phase sequence
Size ; 72 x72 compact, 4-line display
Vt , ct ratio programmable, pulse o/p,
Option : RS 485 communicatons |
 |
| |
| NEMO72B |
L.V application network monitor for 3 phase &
1-phase
Measures A, phase, Ademand,Amax demand,
V-phase
&linked
KW, KV,KVAR, power-phase, demand, max demand
Aneutral, PF,Hz, run hours,
|
 |
| |
| NEMO96 |
L.V./M.V. network monitors for 3-phase
Measures : A, V, Aneutral, HZ,PF, KW,KVA,KVAR
KWH, KVARH, PMD, MD, THD
4-line display , VT / CT ratio programmable,
pulse o/p
Options: RS 485 communication |
 |
| |
| NEMO 96 3D |
L.V. network analyser for three phase
Measures ; A, V, HZ, PF,Aneutral, KW,KVA,KVAR
KWH, KVARH, MD, PMD,
3 line LED display,
CT ratio programmable,
ctsec5A, pulse o/p
Option: Rs 485 communications |
 |
| |
| NEMO 4D |
L.V network analyzer for 3 phase application
Measures : A, Aneutral, V, HZ,PF, KWA,KVA,KVAR
PMD, MD, KWH, KVARH, run hour , phase sequence
3line display ,vt /ct ratio programmable
availabel in flush & din mounting – sleek
& compact, pulse o/p
options: RS 485 communication |
 |
| |
| Multifunction transducers
|
Measuring ; A,V,PF,HZ,P,Q,S,KWH,KVARH
On three phase 4 wire loadline
With RS 485 communication o/p |
 |
| |
| Transducers -TEMAFP |
For measurements of P,Q,S,Pf,Hz,P/Q/Smd measuring
On single pahse or three phase lines
Programmable single /bi-directional analogue o/p
5/10/20ma/5/10v/4-20ma./1-5v
inputs : 50- 500v 1aor 5A , 45—65 hz
Display to show measured quantities |
 |
We can also provide you with modules for multifunction
like analogue output interface, communication interface,
conversion interface for serial communications
We can provide you software for your complete network
monitoring which you can monitor on your PC
Our meters are world wide accepted with many protocols
like Jbus, Modbus, Lon works, profibus and many others
, we can provide meters with specific protocol on request
|
